Equipment shop
Ubiquiti · Ubiquiti wireless and Wi-Fi

Access Point E7

Image 1 of 9Product view

Professional-grade equipment · Installation available
Ubiquiti · Ubiquiti wireless and Wi-Fi

Access Point E7

Read customer reviews
ModelE7Sold as1 unit

Enterprise-grade indoor access point with 10-stream WiFi 7 performance, a 10 GbE uplink, and a redundant GbE port for high availability. Note. 6 GHz operation is supported in these countries . Long-range 6 GHz performance with AFC available in FCC/IC region only.

Top highlights

See more highlights
  • Dedicated spectral analyzer radio
  • Long-range 6 GHz performance with AFC*
  • 185 m² (2,000 ft²) coverage
  • 1,000+ connected devices
  • (1) 10 GbE RJ45 port and (1) GbE RJ45 port for power & data redundancy
  • Backwards compatible mounting system**
  • Powered using PoE++
  • Note. 6 GHz operation is supported in these countries .
  • *Available in FCC/IC region only. ** WiFi Access Point Ceiling Mounts
Product detailsOverview, features and technical specifications

Enterprise-grade indoor access point with 10-stream WiFi 7 performance, a 10 GbE uplink, and a redundant GbE port for high availability. Note. 6 GHz operation is supported in these countries . Long-range 6 GHz performance with AFC available in FCC/IC region only.

At a glance

Highlight 1WiFi 7 with 6 GHz support
Highlight 210 spatial streams
Highlight 3Real-time spectral analysis for enhanced channel selection
Highlight 4Dedicated spectral analyzer radio
More highlights
Highlight 5Long-range 6 GHz performance with AFC*
Highlight 6185 m² (2,000 ft²) coverage
Highlight 71,000+ connected devices
Highlight 8(1) 10 GbE RJ45 port and (1) GbE RJ45 port for power & data redundancy
Highlight 9Backwards compatible mounting system**
Highlight 10Powered using PoE++
Highlight 11Note. 6 GHz operation is supported in these countries .
Highlight 12*Available in FCC/IC region only. ** WiFi Access Point Ceiling Mounts
Access Point E7
Access Point E7

Specifications

BrandUbiquiti
Manufacturer modelE7
InstallationQuoted separately
Max. Client Count1,000
WiFi7WiFi 7
Radio/Antenna6 GHz Radio
Uplink10 GbE
Dimensions250 x 250 x 43.5 mm (9.8 x 9.8 x 1.7")
All specifications (47)
WiFi StandardWiFi 7
Spatial Streams10
Coverage Area185 m² (2,000 ft²)
Max. Client Count1000+
Uplink10 GbE 1 GbE
MountingCeiling, Wall, VESA (Pro Mount Included)
Power MethodPoE++
6 GHz4 x 4 (DL/UL MU-MIMO)
5 GHz4 x 4 (DL/UL MU-MIMO)
2.4 GHz2 x 2 (DL/UL MU-MIMO)
6 GHz11.4 Gbps (BW320)
5 GHz8.6 Gbps (BW240)
2.4 GHz688 Mbps (BW40)
6 GHz6 dBi
5 GHz6 dBi
2.4 GHz5 dBi
6 GHz24 dBm / 30 dBm
5 GHz30 dBm
2.4 GHz23 dBm
Max. BSSIDs8 per Radio
802.11be (WiFi 7)7.3 Mbps to 11.4 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240/320)
802.11ax (WiFi 6)7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
802.11ac (WiFi 5)6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11n6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
Max. Power Consumption43W
Supported Voltage Range42.5–57V DC
Networking Interface(1) 10 GbE RJ45 port (1) 1 GbE RJ45 port
Weight1.8 kg (4 lb)
ManagementEthernet
Enclosure MaterialUV-stabilized polycarbonate, aluminum alloy
Mount MaterialStainless steel (SUS304), galvanized steel (SGCC)
SystemR/G/B
Channel BandwidthHT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
Operating FrequencyUS/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz U-NII-5 to U-NII-8: 5925 - 7125 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5850 MHz 5925 - 7125 MHz
Ambient Operating Temperature-30 to 50° C (-22 to 122° F)
Ambient Operating Humidity5 to 95% noncondensing
CertificationsCE, FCC, IC, Anatel: 06372-24-08356
UniFi NetworkVersion 9.2.87 and later
Mobile AppiOS™ version 10.24.1 and later Android™ version 10.25.2 and later
DownloadsSpecifications, manuals and product documents
