Equipment shop
Ubiquiti · Ubiquiti wireless and Wi-Fi

airMAX NanoBeam 2AC 13 dBi

Image 1 of 6Product view

Professional-grade equipment · Installation available
Ubiquiti · Ubiquiti wireless and Wi-Fi

airMAX NanoBeam 2AC 13 dBi

Read customer reviews
ModelNBE-2AC-13Sold as1 unit

UISP-ready, 2.4 GHz WiFi radio that can serve as a point-to-multipoint station.

Top highlights

See more highlights
  • Dedicated spectral analysis radio
  • Dedicated WiFi management radio
Product detailsOverview, features and technical specifications

UISP-ready, 2.4 GHz WiFi radio that can serve as a point-to-multipoint station.

At a glance

Highlight 12.4 GHz, 15+ km link range
Highlight 2150+ Mbps throughput
Highlight 3Easy mounting
Highlight 4Dedicated spectral analysis radio
More highlights
Highlight 5Dedicated WiFi management radio
airMAX NanoBeam 2AC 13 dBi
airMAX NanoBeam 2AC 13 dBi

Specifications

BrandUbiquiti
Manufacturer modelNBE-2AC-13
InstallationQuoted separately
Dimensions⌀189 x 125 mm (⌀7.4 x 4.9")
Weight530 g (1.2 lb)
Enclosure MaterialsUV-stabilized plastic
MountingPole mount kit (Included) Wall mount (Not included) Window mount (Not included)
Wind Loading45.4 N at 200 km/h (10.2 lbf at 125 mph)
All specifications (33)
Wind Survivability200 km/h (125 mph)
Networking Interface(1) GbE RJ45 port
Power MethodPassive PoE 2-pair (4, 5+; 7, 8 return)
Power Supply24V, 0.5A gigabit PoE adapter (Included)
Supported Voltage Range20–27V DC
Max. Power Consumption7.5W
ESD ProtectionAir/contact: ± 24kV
Buttons(1) Factory reset
Ambient Operating Temperature-40 to 80° C (-40 to 176° F)
Ambient Operating Humidity5 to 95% noncondensing
CertificationsCE, FCC, IC
Salt Fog TestIEC 68-2-11 (ASTM B117) Equivalent: MIL-STD-810 G method 509.5
Temperature shock testIEC 68-2-14
UV testIEC 68-2-5 at 40° C (104° F) Equivalent: ETS 300 019-1-4
Vibration testIEC 68-2-6
Wind-Driven Rain TestETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5
Total Throughput150+ Mbps
Channel Bandwidth10/20/40 MHz
Antenna Gain13 dBi
Max. VSWR1.5:1
PolarizationDual linear
Worldwide2412 - 2472 MHz
US/CA2412 - 2462 MHz
Worldwide5150 - 5250 MHz
US/CAU-NII-3: 5725 - 5850 MHz
DownloadsSpecifications, manuals and product documents
