airMAX PrismStation 5AC

Image 1 of 6Product view

Professional-grade equipment · Installation available
Ubiquiti · Ubiquiti wireless and Wi-Fi

airMAX PrismStation 5AC

Read customer reviews
ModelPS-5ACSold as1 unit

Shielded airMAX AC radio base with airPrism technology.

Top highlights

Product detailsOverview, features and technical specifications

Shielded airMAX AC radio base with airPrism technology.

At a glance

Highlight 1Capable of high-speed, carrier-class links
Highlight 2Dedicated WiFi management radio
airMAX PrismStation 5AC
airMAX PrismStation 5AC

Specifications

BrandUbiquiti
Manufacturer modelPS-5AC
InstallationQuoted separately
DimensionsDevice: 155 x 155 x 104 mm (6.1 x 6.1 x 4.1") Mounting: 83 x 117 x 69 mm (3.3 x 4.6 x 2.7")
WeightDevice: 0.8 kg (1.7 lb) Mounting: 0.8 kg (1.7 lb)
MountingPole Mount (Included)
Wind Loading31 N at 200 km/h (7 lbf at 125 mph)
Wind Survivability200 km/h (125 mph)
All specifications (24)
Networking Interface(1) GbE RJ45 port
Power MethodPassive PoE 2-pair (4, 5+; 7, 8 return)
Power Supply24V, 1A gigabit PoE adapter (Included)
Supported Voltage Range20—27V DC
Max. Power Consumption10W
RF Connections(1) GPS
Ambient Operating Temperature-40 to 70° C (-40 to 158° F)
Ambient Operating Humidity5 to 95% noncondensing
CertificationsCE, FCC, IC, Anatel: 05157-18-08356
QoSWMM packet classification with user-level priority: High, Medium, Low
Max. VSWR2:1
PolarizationDual-Linear
Worldwide5150 - 5875 MHz
US/CAU-NII-1: 5150-5250 MHz U-NII-2A: 5250-5350 MHz U-NII-2C: 5470-5725 MHz U-NII-3: 5725-5850 MHz
Worldwide2412 - 2472 MHz
US/CA2412 - 2462 MHz
DownloadsSpecifications, manuals and product documents
