Access G2 Reader Pro

Image 1 of 5Product view

Professional-grade equipment · Installation available
Ubiquiti · Door access control

Access G2 Reader Pro

Read customer reviews
ModelUA-G2-ProSold as1 unit

Second generation, indoor/outdoor NFC reader and intercom.

Top highlights

See more highlights
  • IP55-rated weather resistance (-10 to 45° C)
  • Connects to UniFi Access Hub using PoE
Product detailsOverview, features and technical specifications

Second generation, indoor/outdoor NFC reader and intercom.

At a glance

Highlight 1Unlock using the NFC card, PIN, UniFi Endpoint mobile app and face unlock
Highlight 2Doorbell for unlock with video of visitor and two-way intercom
Highlight 3Video works as ADA-compliant mounting height
Highlight 4IP55-rated weather resistance (-10 to 45° C)
More highlights
Highlight 5Connects to UniFi Access Hub using PoE
Access G2 Reader Pro
Access G2 Reader Pro

Specifications

BrandUbiquiti
Manufacturer modelUA-G2-Pro
InstallationQuoted separately
NFCNFC
Physical UnlockPin Unlock
SoundTwo-Way Audio
WeatherproofOutdoor Exposed
Dimensions160 x 40.4 x 40.55 mm (6.3 x 1.59 x 1.6")
All specifications (46)
UniFi Application SuiteProtect Access
WeatherproofingIP55
UL 294 LevelDestructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I
Weight136 g (4.8 oz)
Enclosure MaterialPolycarbonate, glass
Mount MaterialAluminum alloy
MountingWall, gang-box mount (Included) Angle mount, junction box (Optional)
Indoor and Outdoor UseYes
Networking Interface(1) GbE RJ45 port
ConnectivityBLE 4.2 NFC
Power MethodPoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU
Max. Power Consumption6W
Supported Voltage Range48V DC
ESD/EMP ProtectionAir: ± 15kV, contact: ± 8kV
Max. Frame Rate30 FPS
Resolution2MP 1200 x 1600 (3:4)
Resolution12 MP (3072 × 4096)
Field of ViewH: 98.6°, V: 125.7°, D: 157.8°
SensorsProximity sensor
Size120 mm (4.7") diagonal
Screen TechnologyCapacitive touch
Luminance480 nits (Typical)
Screen OrientationPortrait
Resolution1280 x 286 px
LEDsR/G/B/W/Amber Learn More
Button(1) Factory reset
NFC Frequency13.56 MHz
NFC Read Range< 30 mm (1.18'')
NFC TechnologyISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T
PoE Cabling RequirementsCat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable.
UL 294 StatementCompliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
CAN/ULC-60839-11-1 GradeGrade assignment: I
CertificationsCE, FCC, IC, SRRC, UL 294, CAN/ULC-60839-11-1
Document number, and issue date and/or revision levelUA-G2-Pro/UA-G2-Pro-Black, V02
Ambient Operating TemperatureDevice: -30 to 45° C (-22 to 113° F) Display: -10 to 45° C (14 to 113° F)
Ambient Operating Humidity5 to 90% noncondensing
Management ApplicationAccess
Software InformationThe software version can be checked at https://unifi.ui.com
