Equipment shop
Ubiquiti · Network cable and fiber

CWDM Mux Demux 4

Image 1 of 5Product view

Professional-grade equipment · Installation available
Ubiquiti · Network cable and fiber

CWDM Mux Demux 4

Read customer reviews
ModelUACC-CWDM-4Sold as1 unit

Rack-mountable 4-channel CWDM mux demux designed to increase capacity of existing fiber infrastructure.

Top highlights

Product detailsOverview, features and technical specifications

Rack-mountable 4-channel CWDM mux demux designed to increase capacity of existing fiber infrastructure.

At a glance

Highlight 1(4) 1270/1290/1310/1330 nm channel ports
Highlight 2(1) Duplex LC UPC communication port for linking to another CWDM Mux Demux 4 with a pair of single-mode fiber cables
Highlight 3(1) Duplex LC UPC monitor port for seamless observation with a power meter or optical spectrum analyzer
CWDM Mux Demux 4
CWDM Mux Demux 4

Specifications

BrandUbiquiti
Manufacturer modelUACC-CWDM-4
InstallationQuoted separately
Dimensions442 x 120 x 43.7 mm (17.4 x 4.7 x 1.7")
Enclosure MaterialSGCC steel
Weight1.4 kg (3.2 lb)
Pigtail and Connector Type0.9 mm white LC/UPC
Connector(1) COM (LC/UPC) (1) MON (LC/UPC) (4) 1270/1290/1310/1330 nm (LC/UPC)
All specifications (23)
TypeSMF-28e
Length≥0.5 to 1 m
IsolationAdjacent Channel: Max. 30 dB Non-Adjacent Channel: Min. 40 dB
Channel Count4 CH Mux/Demux
Channel Center Wavelength1270/1290/1310/1330 nm
Min. Channel Passband±6.5 nm
Insertion Loss<1.5 dB (Max.)
Return Loss50 dB (Min.)
Max. Power Handling500 mW
Max. Passband Ripple0.3 dB
Max. Polarization Dependent Loss0.1 dB
Max. Polarization Mode Dispersion0.1 ps
Min. Directivity55 dB
Ambient Storage Temperature-40 to 90° C (-40 to 194° F)
Ambient Operating Temperature-30 to 75° C (-22 to 167° F)
DownloadsSpecifications, manuals and product documents
