Cloud Gateway Industrial

Image 1 of 11Product view

Professional-grade equipment · Installation available
Ubiquiti · Ubiquiti gateway and switching

Cloud Gateway Industrial

Read customer reviews
ModelUCG-Industrial (270W)Sold as1 unit

Ruggedized, fanless 10 GbE UniFi Cloud Gateway delivering 350W of total system power for high-density PoE deployments, with advanced routing capabilities and microSD storage for full UniFi application support. *The onboard SIM slots are exclusively for Remote SIM integration with the UniFi 5G Max Outdoor. Support coming soon via software update.

Top highlights

Product detailsOverview, features and technical specifications

Ruggedized, fanless 10 GbE UniFi Cloud Gateway delivering 350W of total system power for high-density PoE deployments, with advanced routing capabilities and microSD storage for full UniFi application support. *The onboard SIM slots are exclusively for Remote SIM integration with the UniFi 5G Max Outdoor. Support coming soon via software update.

At a glance

Highlight 1Equipment only; installation is quoted separately
Highlight 2Select the required configuration before ordering
Cloud Gateway Industrial
Cloud Gateway Industrial

Specifications

BrandUbiquiti
Manufacturer modelUCG-Industrial (270W)
InstallationQuoted separately
IDS/IPS5 Gbps
Max. Client Count500
DimensionsDevice: 307.9 x 203.5 x 43.7 mm (12.1 x 8 x 1.7") Table stand: 203.5 x 100.2 x 21.9 mm (8 x 3.9 x 0.9")
Managed UniFi Devices50+
Managed Cameras(15) HD (8) 2K (5) 4K
All specifications (58)
Managed Access Hubs50
Simultaneous Users Connected500+
Max. WAN Port Count5
Default WAN Ports(1) 10G SFP+ (1) 10 GbE RJ45 (1) 2.5 GbE RJ45
2.5 GbE RJ454 (2 PoE+++, 2 PoE+) (2.5G/1G/100M)
10 GbE RJ451 (PoE+++) (10G/5G/2.5G/1G/100M)
10G SFP+1 (10G/1G)
IDS/IPS Throughput5 Gbps
Form FactorWall-mounted Compact desktop (Table stand included) Rack mount (Accessory sold separately)
Coverage Area115 m² (1,250 ft²)
IDS/IPS Signatures55,000+ with CyberSecure
MAC Address Table Size4,000
WiFi Standard802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7)
5 GHz4.3 Gbps
2.4 GHz688 Mbps
5 GHz2 x 2 (DL/UL MU-MIMO)
2.4 GHz2 x 2 (DL/UL MU-MIMO)
5 GHzStub antenna: 5 dBi Terminal (Omni) antenna: 6 dBi
2.4 GHzStub antenna: 3 dBi Terminal (Omni) antenna: 6 dBi
5 GHz26 dBm
2.4 GHz23 dBm
802.11be (WiFi 7)7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
802.11ax (WiFi 6)7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5)6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11n6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b1, 2, 5.5, 11 Mbps
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
NVR StoragePre-installed 128 GB microSD for NVR
Expansion SlotMicroSD Card
PoE BudgetDC input: 270W ATX power: 75W
PoE+30W
PoE+++90W
Voltage Range PoE Mode50-57V
Max. Power Consumption28W (Excluding PoE output)
Power Method(1) DC Input (350W PSU) (1) ATX power (48V)
Power Supply54V DC, 350W (Adapter included) ATX power (48V)
Supported Voltage Range100–240V AC
Heat Dissipation95 BTU/hr (Excluding PoE output)
ProcessorQuad-core ARM® Cortex®-A73 at 2.2 GHz
System Memory3 GB
WeightDevice: 2.4 kg (5.3 lb) Table stand: 321 g (11.3 oz)
Enclosure MaterialDevice: Polycarbonate, aluminium alloy Table stand: Polycarbonate, galvanized steel, silicone rubber
ManagementEthernet Bluetooth
Button(1) Factory reset (2) Handle release buttons
ESD/EMP ProtectionAir: ± 8kV, contact: ± 4kV
Ambient Operating Temperature-30 to 50° C (-22 to 122° F)
Ambient Operating Humidity5 to 95% noncondensing
CertificationsCE, FCC, IC
Mobile AppUniFi iOS™: Version 10.32.0 and later UniFi Android™: Version 10.35.0 and later
DownloadsSpecifications, manuals and product documents
