Equipment shop
Ubiquiti · EV charger

EV Station Pro

Image 1 of 6Product view

Professional-grade equipment · Installation available
Ubiquiti · EV charger

EV Station Pro

Read customer reviews
ModelUC-EV-Station-ProSold as1 unit

Weatherproof, 11 kW Level 2 electric vehicle charging station with an ultra-bright 10.1" touch display, flexible access control, and payment terminal accessory support. Note . UniFi Access must be running on the same console as UniFi Connect with a Control Hub and Access Reader adopted for NFC card registration. Payment Terminal and UniFi WiFi Auto-Link supported with EV Station Pro version 1.2.25 and later. Third-party WiFi configuration is not supported.

Top highlights

See more highlights
  • Access control with QR code scanning, UniFi Identity mobile app, and NFC card*
  • Payment terminal accessory support for payment processing**
  • Hardwire or use one of the included NEMA 14-50 and 6-50 cables for plug-in installation
  • Connected with UniFi WiFi Auto-Link** or Ethernet
  • UL certified
  • Includes wall mount
  • *UniFi Access must be running on the same console as UniFi Connect with a Control Hub and Access Reader adopted for NFC card registration. **Payment Terminal and UniFi WiFi Auto-Link supported with EV Station Pro version 1.2.25 and later. Third-party WiFi configuration is not supported.
Product detailsOverview, features and technical specifications

Weatherproof, 11 kW Level 2 electric vehicle charging station with an ultra-bright 10.1" touch display, flexible access control, and payment terminal accessory support. Note . UniFi Access must be running on the same console as UniFi Connect with a Control Hub and Access Reader adopted for NFC card registration. Payment Terminal and UniFi WiFi Auto-Link supported with EV Station Pro version 1.2.25 and later. Third-party WiFi configuration is not supported.

At a glance

Highlight 1Ultra-bright 10.1" touch display
Highlight 211 kW max charging output with SAE J1772 charging plug
Highlight 3Media content playback for digital signage applications
Highlight 4Access control with QR code scanning, UniFi Identity mobile app, and NFC card*
More highlights
Highlight 5Payment terminal accessory support for payment processing**
Highlight 6Hardwire or use one of the included NEMA 14-50 and 6-50 cables for plug-in installation
Highlight 7Connected with UniFi WiFi Auto-Link** or Ethernet
Highlight 8UL certified
Highlight 9Includes wall mount
Highlight 10*UniFi Access must be running on the same console as UniFi Connect with a Control Hub and Access Reader adopted for NFC card registration. **Payment Terminal and UniFi WiFi Auto-Link supported with EV Station Pro version 1.2.25 and later. Third-party WiFi configuration is not supported.
EV Station Pro
EV Station Pro

Specifications

BrandUbiquiti
Manufacturer modelUC-EV-Station-Pro
InstallationQuoted separately
Dimensions280 x 178 x 143 mm (11 x 7 x 5.6”)
MountingWall Mount or Stand
Power Input200–240V ~ 50A, 50/60Hz, 1φ
Power Output200–240V ~ 50A, 50/60Hz, 1φ
WeatherproofingType 3R
All specifications (25)
WeightWith wall mount/charging gun/power cord: 8.1 kg (17.9 lb)
Enclosure MaterialFront modules: Polycarbonate Middle module: Aluminum, Polycarbonate
Mount MaterialPolycarbonate
Charging Cable Length7 m (23 ft)
Size257 mm (10.1") diagonal
Resolution800 x 1280 (10:16)
Luminance800 nits (typical)
ProcessorOcta-core Arm® Cortex®-A53, 2.2 GHz
Connectivity(1) GbE RJ45 port (1) USB-C port for payment terminal accessory Bluetooth® 4.2
Max. load70A: 50A 60A: 48A 50A: 40A 40A: 32A 30A: 24A 20A: 16A
Plug-in70A: No 60A: No 50A: Yes 40A: Yes 30A: Yes 20A: Yes
Hardwired70A: Yes 60A: Yes 50A: Yes 40A: Yes 30A: Yes 20A: Yes
WiFi Standards802.11 a/b/g/n/ac
Ambient Operating Humidity5 to 90% noncondensing
Ambient Operating Temperature-40 to 50° C (-40 to 122° F)
CertificationsFCC, IC, UL
Management ApplicationUniFi Connect: Version 3.2.4 and later UniFi Connect iOS™ and Android™: Version 2.2.1 and later
DownloadsSpecifications, manuals and product documents
