Ubiquiti · Network video recorder

Network Video Recorder Instant Kit

Image 1 of 17Product view

Professional-grade equipment · Installation available
Ubiquiti · Network video recorder

Network Video Recorder Instant Kit

Read customer reviews
ModelUNVR-Instant-KitSold as1 unit

Compact UniFi Protect NVR Kit, includes (1) UniFi Protect NVR Instant with (4) G5 Turret Ultra cameras and (1) 1TB HDD, delivering an all-in-one solution for fast and effortless setup. Note. Requires connection to a Gateway or Layer 3 switch.

Top highlights

Product detailsOverview, features and technical specifications

Compact UniFi Protect NVR Kit, includes (1) UniFi Protect NVR Instant with (4) G5 Turret Ultra cameras and (1) 1TB HDD, delivering an all-in-one solution for fast and effortless setup. Note. Requires connection to a Gateway or Layer 3 switch.

At a glance

Highlight 1Equipment only; installation is quoted separately
Highlight 2Select the required configuration before ordering
Network Video Recorder Instant Kit
Network Video Recorder Instant Kit

Specifications

BrandUbiquiti
Manufacturer modelUNVR-Instant-Kit
InstallationQuoted separately
Dimensions220 x 220 x 47 mm (8.7 x 8.7 x 1.9")
Managed Cameras(15) HD (8) 2K (6) 4K
Max. Simultaneous Viewport Streams6 4K cameras
Managed Access Hubs50
Storage Capacity(1) 3.5" drive bay
All specifications (72)
Networking Interface(1) GbE RJ45 uplink port (6) GbE PoE RJ45 downlink ports (1) HDMI port (Viewport)
Form FactorCompact Desktop
MountingWall, Din rail mount (Included)
Management ApplicationUniFi Protect UniFi Access UniFi Connect
Hard Drive Capacity(1) 3.5" HDD support
Max. Power Budget for Drives11W
Max. Power Consumption9W
Power MethodUniversal AC input, 100–240V AC, 1.5A Max, 50/60 Hz
Power SupplyAC/DC, Internal, 60W
PoE Budget40W
PoE15.4W
Voltage Range PoE Mode44–57V
ProcessorQuad-core ARM® Cortex®-A55 at 1.7 GHz
Memory4 GB
ManagementEthernet Bluetooth
Display1.14" screen
Weight1.04 kg (2.3 lb)
Enclosure MaterialsPolycarbonate
Mount MaterialPolycarbonate
Ambient Operating Temperature0 to 40° C (32 to 104° F)
Ambient Operating Humidity5 to 95% noncondensing
CertificationsFCC, IC, CE, Electrical Safety
Dimensions⌀90 x 71.2 mm (⌀3.5 x 2.8")
IR Night Vision30 m (98 ft)
Resolution2K
Field of ViewH: 102.4°, V: 54.9°, D: 120.6°
AudioMicrophone
WeatherproofingIP66
Tamper ResistanceIK04
MountingWall, ceiling mount (Included) Junction box, arm mount (Optional)
Networking Interface10/100 MbE RJ45 port
Image SettingsColor, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
Max. Frame Rate30 FPS
Resolution4MP 2688 x 1512 (16:9)
Sensor1/2.4" CMOS
LensFixed focal length
Night ModeBuilt-in IR LED illumination and IR cut filter
Max. Power Consumption4W
Supported Voltage Range37—57V DC
Power MethodPoE
ProcessorDual-core Arm® Cortex®-A7 based chip
Weight330 g (11.6 oz)
Enclosure MaterialAluminum alloy, UV-stabilized polycarbonate
Button(1) Factory reset
Cable Connector TypeRJ45
Cable Diameter5 mm (0.2")
Cable Length30 cm (1 ft)
Jacket MaterialPolycarbonate
Jacket Enclosure Dimensions⌀20 x 70.6 mm (0.8 x 2.8")
Jacket Enclosure MaterialThermoplastic elastomer, polycarbonate, silicone rubber
Ambient Operating Temperature-30 to 50° C (-22 to 122° F)
Ambient Operating Humidity0 to 90% noncondensing
CertificationsCE, FCC, IC
Dimensions147 x 101.6 x 26.1 mm (5.75 x 4 x 1")
Hard Disk Form Factor3.5-inch
Weight0.45 kg (0.99 lb)
Storage Capacity1 TB
Power Method5V/12V input
Management InterfaceSATA 6 Gb/s
Rotation Speed5400 RPM
Workload Rating180 TB/year
Mean Time Between Failure (MTBF)1,000,000 h
Ambient Operating Temperature0 to 65° C (32 to 149° F)
CertificationsFCC, CE, TUV, RCM, KC, BSMI
DownloadsSpecifications, manuals and product documents
