UPS PoE Switch Mission Critical
ModelUSW-Mission-Critical (120W)Sold as1 unit
A switch with an integrated 368Wh lithium-ion battery capable of providing uninterruptible PoE to 8 devices.
Top highlights
- (4) GbE PoE+, (4) GbE PoE++ ports
- (1) GbE port
- (2) 110V AC outputs; 120W total PoE available
See more highlights
- Battery backup power system
- Internal battery 368Wh
Product detailsOverview, features and technical specifications
A switch with an integrated 368Wh lithium-ion battery capable of providing uninterruptible PoE to 8 devices.
At a glance
| Highlight 1 | (4) GbE PoE+, (4) GbE PoE++ ports |
|---|---|
| Highlight 2 | (1) GbE port |
| Highlight 3 | (2) 110V AC outputs; 120W total PoE available |
| Highlight 4 | Battery backup power system |
More highlights
| Highlight 5 | Internal battery 368Wh |
|---|
Specifications
| Brand | Ubiquiti |
|---|---|
| Manufacturer model | USW-Mission-Critical (120W) |
| Installation | Quoted separately |
| Dimensions | 442 x 480 x 44 mm (17.4 x 18.9 x 1.7") |
| 1 GbE RJ45 | 9 (4 PoE+; 4 PoE++) (1G/100M/10M) |
| Max. PoE Output | Up to PoE++ |
| Total PoE Availability | 120W |
| Redundancy | Battery Power Backup |
All specifications (38)
| Form Factor | Rack mount (1U) |
|---|---|
| Switching Capacity | 18 Gbps |
| Total Non-Blocking Throughput | 9 Gbps |
| Forwarding Rate | 13 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 8,000 |
| Packet Buffer Size | 0.5 MB |
| IPv4 | 128 |
| MAC | 128 |
| PoE+ | 4 |
| PoE++ | 4 |
| PoE+ | 32W |
| PoE++ | 60W |
| Max. Power Consumption | 50W (Excluding PoE Output) 240W (Including PoE Output and AC Output) |
| Power Method | Universal input, 100–240V AC, 50/60 Hz External battery input, 48V DC |
| Power Input Method | AC input DC input (Backup) |
| Power Supply | AC/DC, internal, 240W |
| Supported Voltage Range | 100–240V AC |
| Management | Ethernet AR |
| Heat Dissipation | 170.6 BTU/hr (Excluding PoE Output) |
| Weight | Without mount: 9 kg (19.9 lb) With mount: 9.2 kg (20.3 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| Supported Rack Depth | 482.6 mm (19") four-post racks Posts depths ranging from 700 to 1,000 mm (27.6–39.4”) |
| LCM Display | 1.3" touchscreen |
| ESD Protection | Air/contact: ± 24kV |
| Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC, Anatel: 06679-25-08356 |
| UniFi Network | Version 6.2.26 and later |
